BFL-T2/BFL-R2 is a double RF over Fiber module with selectable filters and remote control interface.

BFL-T2 is equipped with two optical laser which trasform an RF signal to an optical signal.
BFL-R2 is equipped with two photodiode which trasform an optical signal to an RFsignal.

Both the models can work in

• IFB mode: to send low power IFB/IEM signal over fiber to a remote area
• ANT mode: to receive signal from an antenna placed on a remote area

FEATURES:

• Wide RF band: 170-1260 MHz
• Easy configuration thru an high contrast OLED white display and 4 key navigation buttons
• Monitor & control through Ethernet, Bluetooth and LoRa
• Operating voltage range: 9 ÷ 18 Vdc
• 2 RGB LEDs for system status indication

BFL-T2:

• 6mW optical laser to cover miles away
• Remote control of Wisycom antennas (LFA, ADFA and BFA)
• 20 band pass filters and 40 Mhz tunable filter software selectable to increase RF robustness
• compatible with expansion board EXP3 (code: BFL-T2_M0-D1)

BFL-R2:

• DC power for external amplifier 12V 200mA for PAW or LBP (on IFB mode)
