Waves Live DSPRO StageGrid 1000

SoundGrid stagebox, perfect for use with the eMotion LV1 live mixer.
DSPRO StageGrid 1000 is a compact I/O device for eMotion LV1 live mixing systems. Use this versatile unit close to your mixing console to add more inputs and outputs at FOH or monitors, or on stage to add more inputs and outputs for stage performers.

With digitally controlled 8 mic/line ins, 4 balanced analog outputs, and an AES/EBU stereo I/O, this 1U rack unit offers the perfect balance between size and functionality, delivering exceptional, no-compromise sound quality and reliability.

The rugged, road-ready StageGrid 1000 is powered by the same proven audio interface as the larger DSPRO StageGrid 4000, making the DSPRO StageGrid family the perfect I/Os for the most demanding live mixing environments.

StageGrid 1000 is fully compatible with Waves’ SoundGrid ecosystem. It interfaces with SoundGrid hosts and network components to make up a modular, scalable audio distribution infrastructure, which can process multichannel audio at ultra-low latency using Waves’ award-winning plugins..

Spesifikasjoner:
Compact SoundGrid stagebox perfect for the eMotion LV1 mixer
Ideal fpr use at FOH or monitors
8 Analog mic/line Inputs
4 Analog line outputs
1 Stereo AES / EBU Digital inputs
1 Stereo AES / EBU Digital outputs
Sample Rate: 44.1 kHz - 96 kHz
2 Headphone outs with individual volume controls
Word Clock input and output,
BNC connectors
SoundGrid Ethernet connection
AC power supply


Dimensjoner
Height: 44 mm (1RU)
Width: 430 mm (for 19” rack)
Depth: 300 mm (not including connectors)
Weight: 2.89 Kg
