Studio Technologies Model 5402

Dante Leader Clock

Varenr: 122346
-+
Bestillingsvare (7 dager)
BeskrivelseTeknisk infoRESSURSER
Beskrivelse

The Model 5402 Dante Leader Clock with GNSS Synchronization provides precise timing signals for applications that utilize the Dante audio-over-IP (AoIP) media networking technology. The unit implements a high-performance IEEE® 1588 precision time protocol (PTP) server, compatible with the requirements of Dante and capable of simultaneously supporting the timing needs of up to hundreds of Dante-compatible devices. As expected, the Model 5402 provides the PTPv1 (IEEE 1588-2002) compatibility that's required by Dante. In addition, the unit supports PTPv2 (IEEE 1588-2008) for AES67 applications. The unit includes an integrated GNSS (satellite) receiver to allow a precise timing reference to be acquired from the major constellations, including GPS, Galileo, and BeiDou. A multi-band GNSS antenna is included with each Model 5402.

Key Features

  • Dedicated Leader clock for Dante audio-over-IP, AES67, ST 2110, and DDM applications
  • High-performance IEEE 1588 PTP v1 and v2 servers
  • Integral GNSS (satellite) receiver for nanosecond-level timing accuracy (multi-band antenna included)
  • Supports major constellations, including GPS (USA), Galileo (Europe), and BeiDou (China)
  • Precision word clock output
  • Eight configurable audio tone signals
  • Three Gigabit Ethernet interfaces support independent redundant Dante and management networks
  • Webpage management and USB flash drive software updating
  • AC mains and 12 volts DC powering
  • Lightweight enclosure, single rack-space (1U) mounting
Teknisk info

Produktinformasjon

- Grensesnitt (Protokoll)
  • Dante
  • SMPTE 2110
  • WordClock
