Extremely wide frequency range. Focused
pick-up. Outstanding transient response. As a condenser microphone, the e
614 convinces in demanding scenarios with a natural, full sound. Its
wide frequency range captures nearly every instrument; its extraordinary
dynamics conjure fine nuances from the air, giving them space and
depth.
Thanks to the precise directivity, the e 614 safely reduces the bleed
from other instruments on stage or in the studio. With its high maximum
sound pressure level, it is especially designed for percussion and as an
overhead mic, but also effortlessly supports stringed and woodwind
instruments.
| Dimensions |
Ø 20mm, L = 100mm |
| Connector |
XLR-3 |
| Frequency response |
40 - 20000 Hz |
| Transducer principle |
pre-polarised condenser microphone |
| Weight |
93 g |
| Pick-up pattern |
super-cardioid |
| Sensitivity in free field, no load (1kHz) |
3 mV/Pa = - 50dB (0 dB = 1 V/Pa) |
| Nominal impedance |
50 O |
| Min. terminating impedance |
1000 O |
| Phantom powering |
12 – 52 V / 3 mA |
| Equivalent noise level |
24 dB(A) |
| Equivalent noise level weighted as per CCIR 468-3 |
35 dB |
| Maximum sound pressure level (passiv) |
139 dB/SPL |
