All specifications are typical
ZSOURCE = 150 O Balanced, 30 ft. XLR cable on specified output
INPUT IMPEDANCE
2.2 kO
MAXIMUM INPUT LEVEL
@ 1 kHz: +24.9 dBu
@ 1 kHz (Main Out): +26.7 dBu
@ 1 kHz (-6dB Out): +20.7 dBu
FREQUENCY RESPONSE
20 Hz to 20 kHz: +/-0.25 dB
10 Hz to 62 kHz: +/- 0.5 dB
5 Hz: << -3 dB
70 kHz: -3 dB
THD+N% (BW 10Hz - 90kHz)
0dBu Input, 1 kHz: < 0.0025%
+20dBu Input, 1 kHz: < 0.008%
NOISE AT MAIN OUTPUT (BW 22Hz - 22kHz)
0dB Gain: -102 dBu
+30dB Gain: -94 dBu
+66dB Gain: -61 dBu
EIN (+66dB Gain): -127 dBu
NOISE AT -6dB OUTPUT (BW 22Hz - 22kHz)
0dB Gain: -107 dBu
+30dB Gain: -100 dBu
+66dB Gain: -67 dBu
EIN (+66dB Gain): -133 dBu
PRODUCT DIMENSIONS (W x D x H)
19” (48.3 cm) x 9.2” (23.4 cm) x 1.75” (4.4 cm)
SHIPPING DIMENSIONS (W x D x H)
24” (61 cm) x 13” (33 cm) x 4” (10.2 cm)
SHIPPING WEIGHT
11 lbs. (5 kg)
