8 Channel Remote Dante Network Mic Preamp

Unrestricted Capacity, Uncompromised Clarity

The most technicallyadvanced microphone preamplifier in Millennia's 28year history. Fully remotecontrollable using Millennia's thirdgeneration AELogic software - forward compatible with our renowned HV3R remote micamp.

Based on years of pro client suggestions, the HV316 is designed for harsh environments and missioncritical applications: live touring racks, scoring stages, remote recording trucks, large studio complexes, sampler houses, hotrack installs, concert halls, outdoor facilities, schools and networked music venues, and environmental recording (12V battery operation).

• 8 channels of pristine Millennia HV-3 microphone preamplifiers in a road-hardened 1U chassis
• Effortless, vividly realistic, dynamically uniform HV-3 musical performance
• Dante network output standard -- analog output option.
• Both 12VDC (battery) and 80-264VAC worldwide powering
• Redundant power supply capability for fail-safe, glitch-free operation
• Paralleled next-generation AKM A-to-D conversion assuring >120dB dynamic range
• Designed for ultra-high-temperature continuous operation (65C / 150F)
• RF “pi filter” shielding provided on analog and digital feeds, destroys mobile interference
• Control up to 256 channels at once via conventional Ethernet.
• +34dBu input headroom for use in the most extreme audio environments
• Matched discrete-octet transistor gain topology, the classic Millennia HV-3 double-balanced circuit
• Ælogic Windows third-generation software offers total control for both HV-316 and HV-3R on the same network
• High-definition meters, grouping, linking, scene management, temperature monitoring
• Entirely balanced audio path with precision components maintains signal integrity: THD under 10 PPM (< .001%)
• Laser-trimmed FET-based output stage (analog output option) drives 1000-foot (300m) cable runs with ease
• All channels matched to 0.08 dB
• Advanced power supply rated for 650,000 hours MTBF operation
• Aluminum 16-gauge rack chassis, ultra-lightweight, just 10 pounds
• Gorgeous NC-machined and hand-polished front panel billet aluminum
• Lovingly hand-built and quality-assured in Northern California USA

Options:

Analog Output Option (8 ch) (16 ch)

HV-316-8 Short-loaded Eight Channel Version (can be upgraded to Sixteen Channels at the factory)
