SC1

SMALL DIAPHRAGM CONDENSER?
?FEATURING INTERCHANGEABLE OMNI AND CARDIOID CAPSULES

OVERVIEW

The SC1 is our first small condenser microphone. It features an interchangeable capsule system and comes with matching omni and cardioid capsules. The SC1 is a transformerless design that offers low self noise, low distortion, ultra fast transient response, and a natural sonic character. The SC1 is precision machined from stainless steel and manufactured in our Detroit based facility. Each pair of capsules is matched for both sensitivity and frequency response in an ISO certified anechoic chamber. The SC1 works great for stereo recordings of drums, rooms, strings, orchestras, piano, and acoustic guitar. Its high SPL capability also makes the SC1 a great choice for snare drums, toms, and electric guitar cabs.

SPECIFICATIONS:

• Directional Pattern - Omni and Cardioid
• Frequency Range - 20Hz-20kHz
• Sensitivity - Omni: 15 mV/Pa - Cardioid: 9 mV/Pa
• Self-Noise - Omni: 14 dBA -  Cardioid: 16 dBA
• Max SPL - 140dB
• Output Impedance - 30 Ohms
• Dimensions - Diameter: 0.90" - 2.3cm - Length: 4.80" - 12.2cm
• Power - 48V Phantom
