Extron SF 8CT SUB SoundField 8" In-Ceiling Subwoofer

Extron SF 8CT SUB

SoundField 8" In-Ceiling Subwoofer

Varenr: 119742
-+
Bestillingsvare (40 dager)
BeskrivelseTeknisk infoTilbehørRESSURSER
Beskrivelse

Extron SF 8CT SUB



The Extron SF 8CT SUB is an in-ceiling subwoofer that complements the Extron range of ceiling speakers by extending the low frequency response in music and high performance audio applications. Designed to be mounted in the ceiling structure, the plenum rated SF 8CT SUB blends in with other ceiling speakers in the system. The 8" (203 mm) low frequency driver delivers rich bass for exceptional audio quality, even from smaller systems. With low and high impedance taps and an integrated low pass filter, the SF 8CT SUB offers the flexibility to meet a wide variety of system requirements.
The SF 8CT SUB extends the low frequency range of any ceiling or program speaker system for improved impact. A subwoofer can cost effectively turn a thin sounding system into a good music playback system or a good music playback system into a great one.



Flexible Installation


For distributed systems, the SF 8CT SUB has an integrated 70/100 volt transformer, allowing placement of multiple subwoofers within a space to provide even coverage from a single amplifier. Power taps at 64, 32, 16, and 8 watts enable the SF 8CT SUB to be placed in low ceiling rooms without being overpowering, or in low SPL applications where low frequencies require additional reinforcement to acheive equal loudness across the audio spectrum.

For installations where more power is required, the SF 8CT SUB can be connected in 8 ohm direct mode, offering up to 200 watts continuous program power handling capability.

A selectable 120 Hz, 6 dB per octave low pass filter is included to simplify setup without the need for additional crossovers.



Powerful Bass


Clean low frequencies, efficiently delivered, can significantly improve how content is received. The 8" driver of the SF 8CT SUB provides tight and powerful bass in a wide variety of applications. The addition of an SF 8CT SUB will eliminate the need to push lower frequencies through small ceiling speakers, resulting in clean bass and overall higher sound quality.





Features



  • 8” (203 mm) low frequency driver in a tuned port enclosure
  • Frequency Range: 45 Hz to 300 Hz
  • 100 watts continuous pink noise
  • 200 watts continuous program
    8 ohm direct or 70/100 volt operation —
    8 ohm direct
    70 volt: 64, 32, 16, and 8 watt selectable
    100 volt: 64, 32, and 16 watt selectable
  • Selectable 120 Hz Low Pass Filter
  • UL 2043 plenum rated
  • Magnetically attached grille with a thin bezel for a refined appearance
  • Locking arms support ceilings up to 2.25" (57.1 mm) thick.
  • Grille and bezel are white and can be painted to match any environment
  • Modular V-rail and folding C-ring kit included
  • Side oriented cable/conduit access plate for easy connection clearance
  • Opti-Torque indicator rings prevent overtightening of locking arm screws
  • Four locking arms for quick ceiling installation
  • UL 94V-0 Fire-resistant baffle with steel back can
  • UL 1480 listed for safety
  • 5-year parts and labor warranty
Teknisk info

Produktinformasjon

- Tilkoblinger (Pluggtype HW) Euroblock / Phoenix / Terminal block
