ATC SCM45A PRO 3veis Studiomonitor

Aktiv, 42Hz-25kHz, 3" Mid, 6,5" LF

Varenr: SCM45A PRO
-+
Bestillingsvare (18 dager)
BeskrivelseTeknisk infoRESSURSER
Beskrivelse

ATC SCM45A Pro  3veis studiomonitor

 Pris. pr. stk. Gir deg kvalitet, nøyaktighet og ytelse.

  • Mid-size very high performance  active 3-way studio monitor
  • Ideally suited to:
    – critical near-field listening applications in all control rooms
    – LCR surround monitoring in medium control rooms
    – surround channels in medium-to-large contol rooms
  • ATC hand built 6.5?/164mm carbon-paper cone bass driver.
  • ATC 25mm/1” Dual-Suspension ‘S-Spec’ Tweeter
  • Discrete MOSFET class A/B tri-amp pack with 150W/60W/25W
    continuous power output

Spesifikasjoner:

Drivers: HF 1?/25mm Dual-Suspension ‘S-Spec’,  Mid 3?/75mm Soft Dome, LF 6.5?/164mm short-coil carbon paper cone
Amplitude Linearity (±2dB): 70Hz-17kHz
Cut-off Frequencies (-6dB, free-standing): 42Hz-25kHz
Dispersion: ±80° Coherent Horizontal, ±10° Coherent Vertical
Max. Continuous SPL (1 metre): 112dB
Audio Input: Rear panel mounted female xlr (pin 2 +)
Input Sensitivity: 1V rms (ref. full output)
Input Sensitivity Trim: 0dB to -6dB/1V – 2V (continuously variable via rear panel trimmer)
Input Impedance: Balanced > 10kO
Amplifier Output Power: Bass 150W rms, Mid 60W rms, High 25W rms
Crossover Frequencies: 380Hz & 3.5Khz
Crossover Filters: 4th order critically damped with phase compensations
Low Frequency Boost: 0dB to +3dB at 40Hz (continuously variable via rear panel trimmer)
Overload Protection: Active FET momentary gain reduction
Dimensions (HxWxD): 353 x 600 x 375mm. Handles add an additional 39mm/1.5? to depth.
Weight: 36kg  (per cabinet)



Teknisk info

Produktinformasjon

- Funksjon & bruk Dolby Atmos
